Plate 015: Future Rapid Transit Routes for Boston 1926

Date: 1926
Publisher: Massachusetts Division of Metropolitan Planning
Size: 13" wide x 22" high
ID: 2023013106
Source Collection: WardMaps LLC
Atlas: Improved Transportation Facilities in the Metropolitan District 1926

Boston in Transit - The Book
Figure 6.19 - Future Rapid Transit Routes for Boston, 1926
Mapped are existing (solid black lines) and proposed (dashed) rapid transit lines for Greater Boston. Many of the proposed lines follow steam railroad rights-of-way. The map was issued with a complimenting map of existing and proposed rapid transit lines in central Boston (Figure 6.20).
