BTC Annual Report 19, 1913 Plate 06: Washington Station Cross Section

Publisher: Boston Transit Commission
Size: 9" wide x 6.25" high
ID: 17104
Collection: Boston Transit Commission Annual Report 19, 1913
Source Collection: WardMaps LLC

Boston in Transit - The Book
Figure 5.127 - Cross-section of Washington Station, 1913
A cross-section of Washington Station shows the stacked arrangement of Summer Street (top), the station’s concourse (middle), and the station’s tracks and platforms (bottom).
