BTC Annual Report 05, 1899 Plate 11: Charlestown Bridge, Draw Turntable

Publisher: Boston Transit Commission
Size: 9" wide x 6" high
ID: 17249
Collection: Boston Transit Commission Annual Report 05, 1899
Source Collection: WardMaps LLC

Boston in Transit - The Book
Figure 5.8 - The Charlestown Bridge Draw Turntable, 1899
Scores of wheels allowed the turning of the rotating draw portion of the Charlestown Bridge.
